Making a split tunnel out of eduVPN for mail and intranet only

My institute (IRD) was hacked recently and is strengthening its security by requiring all users to use a VPN. As a result, I can only send mail from Thunderbird on my professional laptop when I’m connected to its eduVPN (an institutional VPN solution). The problem: I’m working in Vietnam and the VPN is hosted in France. I don’t want my whole laptop behind that VPN for the sake of one SMTP server (a ping to 1.1.1.1 went from around 37 ms to around 330 ms on the VPN).

I tweaked and tried a lot of things, and ended up letting the official client connect, then using a NetworkManager dispatcher script to remove the VPN’s catch-all rule and re-enable the tunnel only for the few destinations that really need it (such as the mail server).

Here is the path in order, dead ends included, so you can skip the ones I fell into. If you’re on Linux with NetworkManager and a WireGuard VPN that grabs your whole default route, this should help even if you’re not using eduVPN.

The setup

• A Linux laptop on Wi-Fi (wlan0).
  • This article should apply to any distro, but I’m running EndeavourOS (Arch Linux based) with NetworkManager v1.58.1.
• The official eduVPN Linux client. You open the app, log in through the browser with SSO, and it hands a WireGuard connection named eduVPN to NetworkManager.
  • The client creates a new 12-hour session every time I connect.
  • More on this below.

My goal is to keep my work’s VPN active all the time, but only send the needed traffic (mail, intranet, etc.) through it. The solution needs to be as robust and low-maintenance as possible (zero maintenance would be even better). A set-and-forget setup would be perfect 😇

Idea 1: containerize the VPN and proxy Thunderbird

My first idea: run the VPN in a container (with gluetun or similar), expose a SOCKS5 proxy, and point Thunderbird at it. I’m fine with 1 s of latency on my whole inbox.

To do so, gluetun wants a WireGuard or OpenVPN config file, and eduVPN doesn’t give a clean config through the client. Also, it’s hard to run eduVPN directly in a headless container, as it needs a browser to log in.

Let’s steal a WireGuard config

Looking more closely at what eduVPN is doing, I see that the connection is a WireGuard (lightweight VPN protocol) connection.

More precisely, the client validates my institute’s SSO login and hands its connection (i.e. a WireGuard configuration) to NetworkManager, so the config is in there somewhere¹. Let’s inspect this new connection with NetworkManager’s utility nmcli. By default, nmcli hides the private key (wireguard.private-key: <hidden>), which is needed to rebuild a config file, but not if you ask nicely:

sudo nmcli --show-secrets -g wireguard.private-key connection show eduVPN

There, I got everything and rebuilt an eduvpn0.conf by hand with one nice twist: AllowedIPs set to the mail server’s IP only, instead of the default wildcard (0.0.0.0/0). That makes it a split tunnel by itself: only the mail server goes through the VPN and not the rest of my traffic, and it would even remove the need for Docker. I brought it up with the client disconnected:

$ sudo wg show
interface: eduvpn0
  listening port: 47821

peer: <server-key>
  endpoint: <endpoint>:51820
  allowed ips: <mail-ip>/32
  transfer: 0 B received, 1.45 KiB sent
  persistent keepalive: every 25 seconds

$ ip route get <mail-ip>
<mail-ip> dev eduvpn0 src <tunnel-ip> uid 1000

The route was right. But look at the transfer line: 0 B received, and no latest handshake line at all. My config isn’t connecting.

The reason showed up when I compared my notes: every time I connect and disconnect with the eduVPN client, I get a different public/private key. My explanation (I haven’t verified it server-side) is that each session registers a fresh peer, and the old key is dead as soon as the client disconnects (probably both for GDPR reasons, to avoid identifying users, and to keep the pool of VPN IPs rolling). So we can’t steal a WireGuard config file. 😥

Idea 2: let the client connect, then cut the catch-all rule

If I can’t have my own config, I can still tweak my laptop: I’ll use the client’s connection and change its routing afterwards. How does the client send everything into the tunnel? By having NetworkManager set up the appropriate policy rules:

$ ip rule show
0:      from all lookup local
1:      from all to <tunnel-ip>/21 lookup 51860 suppress_prefixlength 0 proto static
2:      from all to 10.0.0.0/8 lookup main suppress_prefixlength 0 proto static
2:      from all to <netbird-ip>/12 lookup main suppress_prefixlength 0 proto static
2:      from all to <laptop-ip>/16 lookup main suppress_prefixlength 0 proto static
3:      not from all fwmark 0xca94 lookup 51860 proto static
105:    from all lookup main suppress_prefixlength 0
110:    not from all fwmark 0x1bd00 lookup 7120
32766:  from all lookup main
32767:  from all lookup default

In words: the rule at priority 3 sends everything through routing table 51860, whose default route is the tunnel. The WireGuard packets themselves carry a mark (0xca94²) that lets them skip the rule and reach the server through the normal network. Delete the rule, and the catch-all is gone. Then add back a route for what I actually want:

sudo ip rule del priority 3     # Removing IPv4 catch-all rule
sudo ip -6 rule del priority 3  # Removing IPv6 catch-all rule
sudo ip route replace <mail-ip>/32 dev eduVPN # Adding mail server IP to use eduVPN interface

Testing:

$ ip route get 1.1.1.1
1.1.1.1 via <gateway> dev wlan0 src <laptop-ip> uid 1000
$ ip route get <mail-ip>
<mail-ip> dev eduVPN src <tunnel-ip> uid 1000
$ sudo wg show eduVPN
...
  latest handshake: 17 seconds ago
  transfer: 6.70 KiB received, 9.16 KiB sent

The internet goes out through Wi-Fi, the mail server goes through the tunnel, and the handshake is fresh. Routing solved. Then I tried to resolve the mail server’s name, and nothing: I couldn’t resolve my work’s webmail anymore.

It was DNS

The VPN profile pushes a search domain ~., which in resolver language means “send every lookup to the VPN’s DNS servers”. Those servers are only reachable through the tunnel, and I had just removed the tunnel from the picture. Every lookup timed out.

My attempts, in order, all of them wrong:

1. resolvectl revert eduVPN: Failed to revert interface configuration: ... unknown unit. No systemd-resolved³ on this machine.
2. nmcli connection modify eduVPN ipv4.dns-search ...: worked once, then everything reset at the next connect. The journal explains it: the client deletes and recreates the NetworkManager connection every time (connection-delete), so edits to the profile never survive.

• This could be a good solution, but I don’t want to run that command by hand every time, so I’m rejecting it.

3. The same nmcli commands from inside the dispatcher script didn’t work either, for some reason.

The actual culprit, much later: on this laptop /etc/resolv.conf isn’t owned by NetworkManager at all. NetBird, my mesh VPN (I talked about it here), rewrites it. So two systems were fighting over one file, which is probably why my NetworkManager edits kept making things worse.

Long story short, DNS configuration is hard. The fix I went for is to resolve the name at connect time. There’s a good window for it: right after the VPN comes up, the catch-all rule is still in place, so the VPN’s DNS is reachable and answers. Resolve first, then delete the rule, then add the routes. And since eduVPN ends my session every 12 hours anyway, resolving once per connection is fresh enough (I could even build a proper caching system with a caching DNS resolver like unbound… but that’s overkill).

More than one host: routing the institute’s block

Mail works. But I also wanted to reach a couple of institute web services that seem to care where the traffic comes from. Adding hosts by name works (with a simple HOSTS="a b c" list), but the list only grows, and a wildcard like *.ird.fr can’t work: the script routes IP addresses, and DNS has no way to list every host under a domain.

What does work is routing a whole IP block. whois on one of the institute’s addresses:

$ whois <ird-address> | grep -iE 'inetnum|netname|route|descr'
inetnum:        91.203.32.0 - 91.203.35.255
netname:        IRD-NET

91.203.32.0 to 91.203.35.255 is exactly 91.203.32.0/22. One route, a thousand addresses.

There’s a trap, though, and it’s a good one: the VPN server’s own endpoint sits inside that block. If I route the whole /22 into eduVPN, the WireGuard packets to the server get sent into the tunnel itself, and the tunnel dies in a loop. The client’s packets skip the catch-all rule thanks to their mark, but they still follow the main routing table, which now says “this /22 goes into the tunnel”. So the script has to pin the endpoint to the real gateway first.

Where it landed

The final /etc/NetworkManager/dispatcher.d/90-eduvpn-split, with my private values replaced by placeholders:

#!/bin/sh
# root:root, chmod 755. Don't forget this part.
[ "$1" = "eduVPN" ] && [ "$2" = "up" ] || exit 0

HOSTS="mail.ird.fr intra.ird.fr"    # hosted at Renater and elsewhere, resolved by name every time
NETS="91.203.32.0/22"               # IRD-NET, routed as a whole
VPN_DNS="<vpn-dns-1> <vpn-dns-2>"   # the DNS servers pushed by the VPN profile
DNS1=${VPN_DNS%% *}

{ # 0. Save and date the logs
  echo "== $(date '+%F %T') eduVPN up"

  # 1. Resolve via the VPN DNS while the tunnel still carries everything
  IPS4=""; IPS6=""
  for h in $HOSTS; do
    IPS4="$IPS4 $(dig +short +time=2 +tries=1 @"$DNS1" "$h" A    | grep -E '^[0-9.]+$')"
    IPS6="$IPS6 $(dig +short +time=2 +tries=1 @"$DNS1" "$h" AAAA | grep -E '^[0-9a-f:]+$')"
  done

  # 2. Pin the WireGuard endpoint to the real gateway (it sits inside IRD-NET)
  EP=$(wg show eduVPN endpoints | awk '{print $2}' | cut -d: -f1)
  if [ -n "$EP" ]; then
    R=$(ip route get "$EP" mark 0xca94 | head -1 | sed -E 's/ (src|uid) .*//; s/^[0-9.]+ //')
    ip route replace "$EP/32" $R
    echo "endpoint $EP pinned: $R"
  else
    echo "no endpoint found, skipping NETS to avoid a routing loop"
    NETS=""
  fi

  # 3. Drop the catch-all rules
  ip rule del priority 3
  ip -6 rule del priority 3

  # 4. Only these destinations use the tunnel
  for s in $VPN_DNS; do ip route replace "$s/32" dev eduVPN; done
  for n in $NETS;    do ip route replace "$n" dev eduVPN; done
  for a in $IPS4;    do ip route replace "$a/32" dev eduVPN; done
  for a in $IPS6;    do ip -6 route replace "$a/128" dev eduVPN; done

  echo "routed via eduVPN: $VPN_DNS $NETS $IPS4 $IPS6"
} >> /tmp/eduvpn-split.log 2>&1

What each step does:

sudo chmod 755 /etc/NetworkManager/dispatcher.d/90-eduvpn-split

The check after connecting:

$ cat /tmp/eduvpn-split.log
== 2026-10-20 14:31:12 eduVPN up
endpoint <endpoint> pinned: via <gateway> dev wlan0
routed via eduVPN: <vpn-dns-1> <vpn-dns-2> 91.203.32.0/22  <mail-ip>
== 2026-10-21 10:32:00 eduVPN up
endpoint <endpoint> pinned: via <gateway> dev wlan0
routed via eduVPN: <vpn-dns-1> <vpn-dns-2> 91.203.32.0/22  <mail-ip> <internal-host-ip>

$ ip route get <ird-address>
<ird-address> dev eduVPN src <tunnel-ip> uid 1000
$ ip route get <endpoint>
<endpoint> via <gateway> dev wlan0 src <laptop-ip> uid 1000
$ sudo wg show eduVPN | grep handshake
  latest handshake: 20 seconds ago

Two connections, two runs of the script, and the handshake keeps refreshing, so no loop. The script also runs automatically every time I enable the VPN, so there’s no manual task (other than starting the VPN and reconnecting every 12 hours). And I can now send email from Thunderbird without having my whole network travel around the planet.
